Features
- Multi hammer with 4 functions: hammer drilling, drilling without impact in two speeds and chiselling
- Metabo Quick: quick change between SDS Plus hammer chuck and keyless chuck for drilling in wood and metal
- Vario-Tacho-Constamatic (VTC)-Full Wave Electronics for work with materials requiring customised speeds, which remain constant under load
- Thumbwheel for preselection of the speed and impact rate
- Two-speed gear unit: two drilling speeds for effective drilling in wood and metal
- Metabo Marathon motor with dust protection for long service life
- High performance hammer action, precisely mounted in a housing made of aluminium alloy: long-lasting and robust
- Perfect ergonomics thanks to the centre of gravity being near the hand and optimised handle contour
- Bottom switch protected against damage and dust
- Metabo S-automatic safety clutch: mechanical decoupling of the drive for safe working should the drill stop unexpectedly
- Restart protection: prevents unintentional start-up after power supply interruption
- Lockable switch for comfortable working in continuous operation
- Cable-protecting ball joint for optimal freedom of motion when working
360° View
Max. single blow energy (EPTA) | 3.4 J |
Maximum impact rate | 4500 /min |
Rated input power | 1100 W |
Drill-Ø concrete with hammer drills | 28 mm / 1 3/32 “ |
Drill-Ø masonry with core bits | 68 mm / 2 11/16 “ |
Drill Ø steel | 13 / 6 mm // 1/2 / 1/4 “ |
Drill-Ø soft wood | 35 / 30 mm // 1 3/8 / 1 3/16 “ |
No-load speed | 0 – 900 / 0 – 2100 /min |
Revolutions at rated load | 900 / 2100 /min |
Torque | 18 / 18 Nm // 159 / 159 ft. lbs |
Bit retainer | SDS-plus |
Collar diameter | 50 mm / 1 31/32 “ |
Weight (without power cable) | 3.3 kg / 7.4 lbs |
Vibration
Drilling in metal | 4.3 m/s² |
Uncertainty of measurement K | 1.5 m/s² |
Hammer drilling concrete | 13.5 m/s² |
Uncertainty of measurement K | 1.5 m/s² |
Chiseling | 7.2 m/s² |
Uncertainty of measurement K | 1.5 m/s² |
Noise Emission
Sound pressure level | 90 dB(A) |
Sound power level (LwA) | 99 dB(A) |
Uncertainty of measurement K | 3 dB(A) |
