Specification
| Rated Capacity for cooling P rated kW: | 1.46 | ||
| Room size: | 10-15㎡ | ||
| Power input for cooling PEER kW: | 0.560 | ||
| Rated Energy efficiency ratio EERd: | 2.63 | ||
| Rated coefficient of performance COPd: | – | ||
| Power consumption in thermostat-off mode PTO W: | – | ||
| Power consumption in standby mode PSB W: | 0.5 | ||
| Electricity consumption of single duct appliances QSD kWh/h Cooling: | 0.559 | ||
| Electricity consumption of double duct appliances QDD kWh/a Cooling: | – | ||
| Sound power level LWA dB: | 65 | ||
| Global warming potential GWP kg CO2: | 2.3 |
|
Cooling Capacity:
|
5000Btu/hr
|
|
Discharge Side Pressure:
|
3.2MPa
|
|
IP Rating:
|
IPX1
|
|
Maximum Airflow:
|
290m³/hr
|
|
Maximum Water Extraction Rate:
|
8.2L/day
|
|
Noise Level:
|
53dB(A)
|
|
Power:
|
560W
|
|
Refrigerant:
|
R290
|
|
Suction Side Pressure:
|
0.7MPa
|
|
Supply:
|
230V ~ 50Hz
|
|
Nett Weight:
|
18.5kg
|
|
Mass of Refrigerant:
|
115g
|
|
Rated Capacity:
|
1460W
|
|
Maximum Exhaust Hose Length:
|
1.5m
|
|
Energy Rating:
|
A (EER: 2.6)
|
|
Barcode:
|
5054630504198
|
|
